The OSC crusher line has a large bore cylinder, short stroke and a speed valve that creates greater crushing force with a short cycle time.
- Five models with operating weights from 1,345 to 7,590 lbs. and suited to carriers weighing from 6.6 to 52 tons
- Maximum jaw openings from 23.6 to 47.2 in.
- Deliver 69 to 202 tons of cylinder force
- Crushing teeth combine pulverizing wedges and cutter blades made from wear-resistant cast alloy
- Standard built-in pressure relief valve
- Cylinder rod protector and hydraulic cylinder located in the frame to protect against exposure to concrete rubble
- Lightweight, high tensile strength steel box structure
