Schwarze Industries has made an indelible mark in a fiercely competitive market with its revolutionary HyperVAC Pure Vacuum Sweeper. This isn't just another product in the long line of traditional vacuum sweepers. It's an innovation, a game-changer - a testament to Schwarze's commitment to quality and relentless drive for excellence.

The HyperVAC has been meticulously designed to retain the desirable features of traditional vacuum sweepers - such as the ability to remove fines from gutters and pervious pavement - while simultaneously addressing and overcoming their common shortcomings, including noise, dust emissions, and subpar transfer broom performance.

Key to this approach is the incorporation of several new technologies. For instance, the noise level has been significantly reduced through traditional absorption methods and a unique tortuous path sound attenuator[^2^]. Furthermore, the HyperVAC employs various fugitive dust control strategies, including water, debris deceleration through deflection, and cyclonic separation, culminating in a dust separator that also serves as a fan noise attenuator.

But perhaps the most radical departure from traditional vacuum sweepers is the patent-pending Schwarze Vertical Digger Broom Transfer Array. This entirely new material transfer system, coupled with innovative dust separation technology, effectively reduces the release of contaminant air typically seen in pure vacuum sweepers.

The Schwarze HyperVAC is not just a product; it promises superior performance, exceptional quality, and unwavering commitment to customer satisfaction. Because at Schwarze, we don't just make products; we create solutions that matter.

Specifications

Chassis

• The chassis can be mounted on various systems to meet requirements.
• Dimensions: Length ranges from 225 in (6,477 mm) to 275 in (6,985 mm), Width is 96 in (2,438 mm).
• Steering is on the left side, with dual steering as an option.
• The fuel type is diesel.
• It comes with a rear beacon light standard; barlight, strobe lights & arrow board are optional.
• Accessories include a backup camera, spare tire, wheel covers, and more.

Debris Pickup System

• The technology used is Pure Vacuum.
• The system includes 3 transfer scrubbing brooms & a tow bar with 2 vacuum nozzles.
• Width without brooms is 28 in (813 mm), with one broom, it's 108 in (2743 mm), and the maximum width is 138 in (3505 mm).
• The system has a surface area of 250 sq in (2,032 mm) twice, excluding scrubbing brooms.
• It's made with 10 gauge abrasion-resistant steel with rubber seal flaps.

Standard Sweeper Engine (Twin Engine Only)

• The make is John Deere 4045T Tier 4 Final.
• It's a 4-cylinder turbocharged diesel engine.
• Displacement is 275 cu in. (4.5 L) with a horsepower of 134 hp (100 kw) @ 2400 rpm.
• Torque measures 398 ft lb (540 Nm) @1600 rpm.

Control System

• The control system includes a flat panel display, rocker switch banks, and is mounted on a swivel stand.
• The voltage is 12 V with a 90 amp alternator and blade fuse circuit breakers.

Hydraulic System

• Features a variable displacement hydraulic system.
• Pump capacity is 34 gpm (129 lpm) @ 2200 rpm.

Fan System

• The fan system is a closed-face radial Whisperwheel type.
• Construction is Hardox steel with a diameter of 32.75 in (832 mm).

Brooms

• The broom type is a vertical steel digger with Gutter Extension Override (GEO), Power tilt & Pitch control.
• Diameter for side brooms is 39 in (991 mm); Transfer brooms 28 (711 mm).

Debris Hopper

• Volume capacity is 8.4 cu yd (6.4.cu m), constructed from stainless steel.
• Dump angle is 46 degrees with a floor angle of 3 degrees.

Dust Control System

• The dust control system is a dual electric diaphragm pump with run dry capability.
• Capacity ranges from 380 gal (1,438 L) to 600 gallon (2,271 L) with extended chassis.

Backup Hydraulic System

• The backup hydraulic system is a gear type driven by an electric motor.
• Its function is to lower the hopper, open/close hopper door, and raise brooms and pickup head.

Miscellaneous

• The paint job includes one coat of sealer/primer and two coats of Dupont imron elite polyurethane in standard white color; special colors or graphics wrap are optional.
